Amj-560b3 Medical Equipments Portable Mobile Recovery ICU Anesthesia Ventilator Machine

Product Description

AMJ-560B3 Medical Equipments Portable Mobile Recovery ICU Anesthesia Ventilator Machine
Amj-560b3 Medical Equipments Portable Mobile Recovery ICU Anesthesia Ventilator Machine

AMJ-560B3 Anesthesia Machine, with its ergonomic design, integrates a concise and smooth structure and high mobility. The microcomputer-controlled Ventilator adopts exported sensors and other components. Its scientific and proper design as well as rigorous production process are what demonstrate the inner quality of Aokai products: Mechanical ventilation is made secure and visible by the folded respiratory bellows, and the security of air supply is guaranteed by pneumatic transmission and measurement system. With multiple modern technologies applied, the Anesthesia Machine is both outstanding in performance and versatile in functions.
N The Ventilator adopts microcomputer control with high-definition TFT color LCD display, integrating the functions of respiratory control and displaying the monitoring parameters. It is versatile in function and excellent in performance.
The high-precision Vaporizer is designed with a stable concentration output, automatic compensation for pressure, temperature and flow rate. And it is available to choose one kind of gas from Halothane, Enflurane, Isoflurane, and Sevoflurane, ensuring a successful anesthesia operation.
High-definition four-tube flowmeter, designed with stoppers for oxygen and nitrous oxide to control the output oxygen concentration.
Reliable pneumatic transmission system.
Economic and proper configuration of technologies, optional as required by the Customer.
Modularized design and upgrading. Upgrading is available as required by the Customer.

Main body	High-strength engineering plastic rack, light, beautiful and corrosion resistant
Scope of application	adult, child
Gas source	O2: 0.27~0.55MPa N2O: 0.27~0.55MPa
Flow meter	O2: 0.1~1.0L/min 1.1~10L/min N20: 0.1~1.0L/min 1.1~10L/min
O2, N2O linkage and N2O Stopper	When using nitrous oxide, oxygen concentration>25%; When the oxygen pressure<0.2Kpa, the flow of nitrous oxide would be cut off.
Flow rate of rapid oxygen supply	25~75L/min
Low oxygen pressure alarm	There will be sound alarm when the oxygen pressure < 0.2MPa
Vaporizer	it has the function of automatic compensation based on pressure, temperature, and flow rate. The regulation range of evaporator concentration is 0~5 vol%. Among Halothane,Enflurane, Isoflurane and Sevoflurane, one can be chosen for application as required by the customer. And vaporizers that are imported with original packaging are also available.
Respiratory circuit	working mode: all-close, semi-close, semi-open releasing pressure: 0.5~7 kPa
Respiratory Bellows	bellows for adults, bellows for children tidal volume range:0~1,500 ml
