ND -2011 Medical Hollow Drill/ Medical Cannulated Drill
ND-2011 Medical Hollow Drill/ Medical Cannulated DrillComposition:Battery operated surgical drill&saw is made of main hand piece, charger,battery. The whole outer skin of the hand piece is sealed. Charger is not a medical electric device.Main Technical Data:1.Technical data handpieceWorking v......
Send Inquiry
Product Description
ND-2011 Medical Hollow Drill/ Medical Cannulated Drill
Composition:
Battery operated surgical drill&saw is made of main hand piece, charger,battery. The whole outer skin of the hand piece is sealed. Charger is not a medical electric device.
Main Technical Data:
1.Technical data
3.Application
Holds K-wires or be used in intramedullary interlocking nail surgery or arthroscopic surgery .
Notes:
1):Axial run-out of concentricity is within 0.05mm
2):Rotating speed : 0-650/1000 rpm for choices
3):Rotated torque 12.5N.m/ 7.5N.m
4): interface adapt to various drill
5):Semi-luser surface gives comfortable feel
6): Full sealed motor can be sterilized up to 135 °c
7):Multipurpose interface is easier to use in clinic
8): 4.0mm hollow for all brand needles to pass througth
9): NI-MH battery without memory environment
10):Autoclavable
Composition:
Battery operated surgical drill&saw is made of main hand piece, charger,battery. The whole outer skin of the hand piece is sealed. Charger is not a medical electric device.
Main Technical Data:
1.Technical data
| handpiece | Working voltage | 14.4V |
| Output power | ≥20W | |
| Unit rise in temperature | ≤20°C | |
| charger | Input voltage | AC220V,50Hz |
| Output power | 14.4V, 900mA | |
| Input power | 30VA | |
| Battery | voltage | 14.4V |
| Charging time | About 3 hours | |
| Canulate drill | Output voltage | 100W |
| torque | 12.5/7.5N.m | |
| Rotating speed | 0-650/1000rpm | |
| noise | ≤45dB | |
- Standard configuration
| One drill unit |
| One charger |
| Two batteries |
| Two aspetic battery transfer rings |
| One drill chuck key |
| One instruction manual |
| One Aluminum case |
3.Application
Holds K-wires or be used in intramedullary interlocking nail surgery or arthroscopic surgery .
Technical Merits
Notes:
1):Axial run-out of concentricity is within 0.05mm
2):Rotating speed : 0-650/1000 rpm for choices
3):Rotated torque 12.5N.m/ 7.5N.m
4): interface adapt to various drill
5):Semi-luser surface gives comfortable feel
6): Full sealed motor can be sterilized up to 135 °c
7):Multipurpose interface is easier to use in clinic
8): 4.0mm hollow for all brand needles to pass througth
9): NI-MH battery without memory environment
10):Autoclavable
