Titanium Surgical Instruments Cannulas General

Posterior Capsule Polisher
20303 25G
20303H 23G

Air Injection Cannula
20305 27G, 5mm from tip to bend, 19mm long excluding hub
20402 27G, 7mm from tip to bend, 19mm long excluding hub

Nichamin Hydrodissection Cannula
Curved cannula designed to follow the sclera tunnel incision and anterior lens capsule to provide less deformation of the wound and less loss of the anterior chamber. The unique flattened tip allows for a better fit under the capsular leaflet
20306 25G
20439 27G

Lacrimal Cannula
20307 23G, 22mm excluding hub, cannula with bunt tip, straight shaft

Lacrimal Cannula
20308 23G, cannula with reinforced shaft, straight 10mm tip

Lacrimal Cannula
20309 23G, cannula with reinforced shaft, curved 10mm tip.

West Lacrimal Cannula
20310 23G, cannula with blunt tip and bottom port, gently curved shaft

Kratz Capsule Scraper
20311 23G, cannula with 1mm angled sand blasted tip

Kellan Hydrodissection Cannula
20312 Gently curved, 25G,cannula with flattened blunt tip to slip under the anterior capsular flap

Kellan Hydrodissection Cannula
20313 Gently curved, 25G, cannula with tip beveled down for using during Hydrodelineation of the lens nucleus

Randolph Cyclodialysis Cannula
20314 19G, cannula, flattened shafts 12mm from tip to bend, tip has opening.
Viscoelastic Injection Cannula
20315 21G, Cannula 50° shafts 5mm from tip to bend, flattened round tip

Bishop-Harmon Irrigating Cannula
20441 19G, angled 30° degree shafts 5mm from tip to bend with flattened blunt tip.Oveall length excluding hub 25mm

Mclntyre Anterior Chamber Cannula
20405 23G, angled, blunt tip, 12mm from bend to tip, 17mm long excluding hub
20407 26G, angled, blunt tip, 12mm from bend to tip, 15mm long excluding hub
20409 30G, angled, blunt tip, 12mm from bend to tip, 15mm long excluding hub

Knolle Anterior Chamber Irrigating Cannula
20410 23G, angled, blunt tip, 2mm from tip to bend, 19mm long excluding hub
20411 25G, angled, blunt tip, 2mm from tip to bend, 19mm long excluding hub
20412 30G, angled, blunt tip, 2mm from tip to bend, 19mm long excluding hub

Scheie Anterior Chamber Cannula
20413 27G, straight, blunt tip, overall length 20mm excluding hub.

Binkhorst Hooked Cannula
22G, angled 30°, 13mm from tip to bend with 2.5mm hook curved tip, overall length 35mm excluding hub
20418 Left,
20419 Right

Osher J Cannula
20420 27G, 'J' tip, allows easy passage through 2.2mm phaco incision. Tip length 2.5mm. Overall length 25mm excluding hub.

Simcoe Cortex Extractor
Gently curved, 23G, 0.33mm aspiration port
20429 13mm long excluding hub
20430 21mm long excluding hub

Shepard Incision Irrigating Cannula
20442 30G, 5mm flattened angled tip, overall length 18mm excluding hub.

Mclntyre Inner Cannula
20443 23G, 0.3mm side port, overall length 46mm excluding hub
20444 19G, straight uptapered end, onvearll length 17.5mm excluding hub
20445 20G, 0.7mm side port, overall length 46mm excluding hub.
